Technical Specifications ( Non NDI Version )
Imaging
Image Sensor 1/1.3" CMOS sensor | Image Stabilization E.I.S. |
Horizontal Resolution (TV Lines) 2160 TV Lines | Focus Control PDAF (Phase Detection Auto Focus), Manual Focus |
Built in ND Filter No | Image Profile Rec 709, Cine, High Contrast, Vivid, Concert, Gamma |
Exposure Control
Shutter Speed 1/8000 to 1 second | Gain 0 to 24 dB (ISO 800 to 25600) |
White Balance Auto Incandescent Cloudy D10000 Fluorescent Indoor Daylight Shade Manual |
|
Lens
Focal Length 36mm to 648mm (35mm equivalent) | Maximum Aperture f/1.6 (W) / f/3.5 (T) to f/11 |
Optical Zoom Ratio 18x | Minimum Focus Distance Wide: 3.94" /10 cm, Tele: 78.7" / 220 cm |
Max Digital Zoom 36x (in 1080p) | ND No |
Field of View Horizontal: 53º to 3.6º | OLPF No |
Video Capture
External Recording Modes HDMI UHD 4K (3840 x 2160) at 23.98/24/25/29.97/50/59.94 fps HD (1920 x 1080p) at 23.98/24/25/29.97/50/59.94 fps HD (1920 x 1080i) at 50/59.94 fps SDI / BNC HD (1920 x 1080p) at 23.98/24/25/29.97/50/59.94 fps HD (1920 x 1080i) at 50/59.94 fps RJ45 / USB UHD 4K (3840 x 2160) at 24/25/29.97/50/59.94 fps HD (1920 x 1080p) at 24/25/29.97/50/59.94 | Audio Recording 3.5 mm TRS (Mic in / Line in) |
Internal Recording Modes UHD 4K (3840 x 2160) at 23.98/24/25/29.97/50/59.94 fps HD (1920 x 1080p) at 23.98/24/25/29.97/50/59.94 | Broadcast Output NTSC / PAL |
IP Streaming H.264, H.265, RTMP, RTMPS, RTSP, SRT, SSP, UVC, UHD 4K (3840 x 2160) at 24/25/29.97/50/59.94 fps HD (1920 x 1080p) at 24/25/29.97/50/59.94 |
|
Control
Presets 256 via CGI 100 via VISCA 9 via IR | Tally Light Yes |
Move Speed Pan: 0.1 to 180º/sec Tilt: 0.1 to 180º/sec | Supported Control Protocols IR VISCA over RS-422 VISCA over IP Web Client UVC |
Movement Range Pan: 350º (-175º to +175º) Tilt: 240º (-30º to +210º) | FreeD Yes |
Movement Accuracy 0.01º |
|
Interface
Media / Memory Card Slot SD (4K 60fps max, H.265, 8-bit color) | Audio I/O 1x 1/8" / 3.5 mm TRS Stereo Mic/Line Input |
Video I/O 1x BNC (3G-SDI) Output 1x RJ45 (IP) Output 1x HDMI Output 1x USB-C 3.0 Gen 1 Output | Other I/O 1x BNC (Genlock) Input 1x RJ45 (VISCA / RS-422) Input 1x RJ45 (VISCA / RS-422) Output |
Power
PoE Support PoE+ 802.3at | Power Consumption 18W maximum |
Power I/O 1x Barrel (12V DC) Input |
|
Environmental
Operating Temperature 0 °C to 40 °C (32 °F to 104 °F) |
|
General
Mounting 3/8" Screw Hole + 1/4" Adapter Desktop / Ceiling | Environmental Resistance No |
Certifications CE, FCC, RoHS | Color Black |
Dimensions (W X H x D) 6.8 x 9.3 x 7.7" / 175.0 x 235.5 x 195.5mm | Color Black |
Weight 7.4 lb / 3.35 kg (Camera Unit only) 12.0 lb / 5.45kg (Full Package) | Fanless Design Yes |
